MEZZANINE FLOOR GOODS LIFT - MEZZLIFT 250KG

Mezzanine Floor Goods Lift 250kg Description:

The MezzLift 250kg mezzanine floor goods lift is a simple, robust and versatile mezzanine floor lift for handling loads up to 250kg between two floors in warehouses, factories, stores and workshops. Both level gates fitted with electrical and mechanical interlocks.

For a mezzanine floor structure, please find more information on our projects website.

Mezzanine Floor Goods Lift 250kg Features:

• 250kg maximum working load
• Lift speed approx. 0.15m/s
• Usable platform size 1300mm x 1100mm
• Will lift Euro & UK pallets
• 2 stop lift, up to 4000mm travel height
• 2000mm high double gates at both levels
• Electrically interlocked gates
• Constant pressure control buttons at both levels
• Floor mounted, no pit required
• Self-supporting mesh shaft
• Same side or through car loading
• Hazard warning safety signs
• O&M manual
• Emergency stop button
• Anti-slip platform surface
• Hose burst protection
• Overload protection
• Ground to mezzanine floor
• CE marked and built in conformance with: *Machinery Directive 2006/42/EC *Lifting Operations and Lifting Equipment Regulations 1998 *The Provision and Use of Work Equipment Regulations 1998

Why is a MezzLift better than a traditional Goods Lift?

There is no need for a motor room or lift pit leading to immediate cost & space savings. The rugged industrial frame & mechanism give low maintenance requirements & a long life span.

Why is a MezzLift better than a Fork Lift?

Operating a Fork Lift for routine lifts to a mezzanine floor ties up an expensive machine & driver who could be better employed elsewhere. The confined space of a warehouse can also be hazardous for Fork Truck operations. The answer is clear. In contrast, our MezzLifts benefit you with tangible cost savings by removing the need for unnecessary structural changes to their buildings & reducing the risks associated with operating Fork Trucks & unaided manual handling operations.
